Smart LED Controller SZ900-X5, 5 in 1 RGB, RGBW, RGBCCT, CCT, DIM, Tuya LED Strip Light Controller, Bluetooth and WiFi Control, Multi-Zone Sync, Works with Alexa and Google, 12V 24V, 58A Output, 2KHz or 15KHz PWM
SKU:
FTL-0086
- $28.50
$31.35- $28.50
- Unit price
- per
Volume discounts on orders over $500 — See tiers
Volume Quote Request
×Automatic discounts apply at checkout on orders over $500.
SPENDSAVE
$500 – $1,9995%
$2,000 – $3,9996%
$4,000 – $5,9997%
$6,000 – $7,9998%
$8,000 – $9,9999%
$10,000 – $19,99910%
$20,000 – $49,99912%
$50,000+15%
Prefer phone? +1 (678) 538-7884
Thanks — your request was submitted.
Estimated Shipping Widget will be displayed here!
Couldn't load pickup availability
Free Shipping
Free shipping on orders over $99
Ships within 1 business day
Volume Discounts
Automatically applied for orders $500+
Smart LED Controller SZ900-X5 – 5-in-1 RGB/RGBW/RGBCCT/CCT/DIM | Tuya App, Bluetooth & WiFi
The FlipToLed SZ900-X5 Smart LED Controller is a 5-in-1 solution designed to power and control almost any LED strip lighting setup. With support for RGB, RGBW, RGBCCT, CCT (tunable white), and DIM (single color), it’s the most versatile LED controller for both residential and commercial applications.
Featuring Bluetooth and WiFi connectivity, it works seamlessly with the Tuya Smart App, enabling full customization, automation, and multi-zone synchronization. It also integrates with Amazon Alexa and Google Assistant for hands-free voice control.
Engineered with 58A max output current and selectable PWM dimming frequencies (2kHz or 15kHz), the SZ900-X5 ensures smooth, flicker-free lighting control with professional-grade performance.
Key Features
-
5-in-1 Control: Supports RGB, RGBW, RGBCCT, CCT (CW+WW), and DIM (single-color) LED strips.
-
High Power Output: Up to 58A max output current, suitable for large LED installations.
-
Smart App Control: Manage lighting via the Tuya Smart App with WiFi or Bluetooth.
-
Voice Control: Works with Alexa and Google Assistant for hands-free commands.
-
Multi-Zone Sync: Control and sync multiple zones or rooms simultaneously.
-
Selectable PWM Frequency: Choose 2kHz for standard use or 15kHz for flicker-free performance (ideal for film/studio applications).
-
Customizable Scenes & Schedules: Automate lighting effects for daily routines or special events.
-
Wide Voltage Range: Compatible with 12V and 24V DC LED strips.
Product Specifications
| Specification | Details |
|---|---|
| Brand | FlipToLed |
| Model | SZ900-X5 |
| Control Modes | RGB, RGBW, RGBCCT, CCT, DIM |
| Input Voltage | 12V / 24V DC |
| Max Output Current | Up to 58A |
| Control Options | Bluetooth + WiFi (Tuya Smart App) |
| Voice Control | Alexa & Google Assistant |
| Zones | Multi-Zone Sync Control |
| PWM Frequency | Selectable 2kHz or 15kHz |
| Applications | LED strip lights, accent lighting, architectural, commercial setups |
| Warranty | 2 Years |
FAQs
1. What LED strips does the SZ900-X5 support?
It supports RGB, RGBW, RGBCCT, CCT tunable white (CW+WW), and single-color DIM LED strips.
2. How powerful is this controller?
It delivers up to 58A output current, making it suitable for large residential or commercial LED installations.
3. Can I control it without WiFi?
Yes, you can also use Bluetooth control via the Tuya App when WiFi is not available.
4. What’s the benefit of 2kHz vs 15kHz PWM?
-
2kHz: Standard dimming for everyday use.
-
15kHz: Flicker-free dimming, ideal for video, photography, and professional lighting setups.
5. Does it support multi-zone lighting control?
Yes, you can group multiple controllers and sync them for whole-home or multi-room control.
